Magnification

4x / 1x

Length

153mm nominal

Width

74mm nominal

Height

78mm nominal

Weight

660g nominal

Reticle

Dual-thickness ballistic crosshair with user-selectable red dot, VSOR rangefinder, and area fire circles.

Aiming Dot diameter

1.5 MoA @ 4x, 6 MoA @ 1x

Ballistic correction:

Dual-thickness ballistic crosshair with user-selectable red dot, VSOR rangefinder, and area fire circles.

DFOV14-C1:

CX5395 reticle: 100-600m for 5.56 carbine,700-1000m for 5.56mm LMG

DFOV14-C2:

CX5396 reticle: 100-600m for 7.62 rifle, 700-1000m for 7.62mm LMG

CQB offset

<44mm @ 60m

Field of View

26 deg @ 1x, 6.5 deg @ 4x

FoV @4x

11.4 m @ 100 m (34.2 ft @ 100 yds)

FoV @1x

48.8 m @ 100 m (146.3 ft @ 100 yds)

Illumination source

Battery-powered LED

Crosshair illumination

5 settings, AN/PVS-22 compatible

Red Dot illumination

5 settings, AN/PVS-22 compatible

Eye Relief

70mm

Entrance pupil

32mm

Exit pupil

8mm

Nominal focus

150m @ 4x, 70m @ 1x

Fixed focus range

20m to infinity

Battery type

CR2032 (3v Lithium)

Battery life

382hrs on max RD/reticle setting, 1730hrs on second highest RD setting, 1208 hrs on second highest reticle setting

Exterior finish

CERAKOTE® performance finish in Black or Flat Dark Earth (FDE)

Adjustment resolution

0.5 minute of angle

Adjustment range

120 minutes of angle

Base requirement

Mil-Std-1913 ‘Picatinny Rail’

Attachment

A.R.M.S. Levers

Shockproof:

450 g’s
