Magnification

8 ×

Effective lens diameter

54 mm

Exit pupil diameter

6.8 mm

Twilight factor

20.8

Field of view at 1,000 m (yds)

120 m (360 ft)

Subjective viewing angle

54° Ww

Close focusing distance

3.5 m (11.5 ft)

Diopter adjustment range

− 4.0 | + 4.0 dpt

Exit pupil distance

14 mm

Pupil distance

58.5 – 76 mm

Lens type

FL

Prism system

Abbe-König

LotuTec | Nitrogen filled

+ | +

Water resistance

100 mbar

Measuring range

10 – 2,300 m (11 – 2,500 yds )

Measuring accuracy

± 1 – 600 / ± 0.5 % > 600 m (yds)

Measuring duration

< 0.3 Sec

Laser wavelength

905 nm

Laser beam divergence

1.6 × 0.5 nm

Battery

1 × 3V Type CR 2

Battery life at +20°C

> 2.500 ×

Operating temperature

− 30°C | + 63°C (− 22°F | + 145°F)

Length

195 mm (7.7 ")

Width at an interpupillary distance of 65 mm

141 mm (5.6 ")

Weight

1,095 g (38.6 oz)
